Polarity: A change in positive pressure on the diaphragm produces a positive voltage on terminal 2 of the XLR
Free field frequency response, 0°, +/- 1 dB: 10-10000 Hz Free field frequency response, 0°, +/- 2 dB: 10-22000 Hz Sensitivity (@ 250Hz; +/-2 dB ) 15 mV/Pa [-36.5 dB re 1V/Pa] Maximum SPL (THD < 3 %) 140 dB SPL Noise <23 dBA SPL equiv.(typical 22 dBA) Power supply 48 V [5mA] phantom power Temperature coefficient +0.035 dB/°C Operating temperature -10 °C to +50 °C
